- Description
-
Rated load kg 4000 Maximum lift height mm 17550 Maximum reach mm 13080 Maximum traction force kn ≥70 Minimum ground clearance mm 420 Overall dimensions(L×W×H) mm 6970×2430×2550 Minimum width (with hydraulic outriggers fully open) mm 3800 Wheelbase mm 3670 Axle track mm 1990 Rear wheel center to rear mm 1240 Turning radius (outer wheel) mm ≤4500 Maximum travel speed km/h 30 Tire model / 16.8-24 Steering type / 4 wheel drive 3 steering modes Front Wheel Steering Crab Steering Four Wheel Steering Transmission type / Closed piston pump + walking motor + gearbox + drive axle Service brake / Oil-immersed multi-disc hydraulic brake[Disc Brake] Parking brake / Negative braking Weight (with forks) kg 13500 Engine Model / CUMMINS 4BTA3.9-C125（CHINA 2） Power kw/r/min 91/2200 Optional engine CUMMINS QSB3.8（EURO3）/CUMMINS QSF3.8(EPA4) Number of gears (forward/reverse,high/low speed) / 4/4 Gear Control / Electronic control Working hours Lift s 18 Decline 13 Outreach 17 Retracted 16 Tipping up (filling) 5 Tipping down (unloading) 4 Standard fork (L x W x D) mm 1200 x 125 x 50 Hydraulic control system / Multifunctional centralized handle[Overload Protection System] Frame leveling / +/- 9° 1. Compact structure, flexible operation, stable lifting, automatic leveling, high net load load index, and precise fork transportation;
2. CUMMINS engine, low noise, low emission, strong power and large torque reserve;
3. Equipped with a torque limit system to meet the needs of extreme working conditions and ensure operational safety;
4. The fork leveling adopts the automatic flow compensation technology to realize the automatic control of the fork level during the luffing process of the boom to ensure the stability and safety of the high-position fork lift;
5. It has the function of horizontal leveling of the frame, and has strong site adaptability to meet the needs of complex working conditions;
6. Four-wheel drive, with two-wheel steering, four-wheel steering and crab steering mode, strong off-road capability, suitable for different working situations;
7. Advanced human-computer interaction system, instrument monitoring and alarm system are fully functional and easy to operate;
8. The full hydraulic wet braking system can be selected, the braking is stable and reliable, and the driving safety is ensured;
9. Imported dedicated fully electronically controlled gearbox and axle can be selected, with compact structure and high transmission efficiency;
10. It can be configured with high-altitude platforms, buckets and other tools to meet the individual needs of users.
