TL5500
Still deciding? Get samples first, Contact US !
View similar products
Tag list
- Description
-
Technical Parameters
Model Specification Model: MJ5.5 Type performance Mobile, self-loading, mixing and transporting on an integrated chassis Functionality Wet (or dry) mixing of bulk materials such as concrete, mortar, fertilizer compound, feed, etc. and can unload the materials to the destination by itself. Production function Batches ≤ 15 minutes, 4 batches per hour (22 parties) Driver 4 x 4 Redirect Front wheel drive Motor Yuchai 4-cylinder 2200rpm, 115KW. intercooled supercharged Travel speed High speed 40 km/h Low speed 7.5 km/h Gear level 4 forward gears, 4 reverse gears Tires 1670-24 (wire tires) Mixing tank Geometric volume 6.4 m3, optimal mixing 4.5-5.5 m3 Screw blades in tanks Triple helix mixing, with infusion screw, make the mixing material more uniform. Left spiral feeding and right spiral discharging Mixing tank 270 degrees discharge The tank rotates horizontally up to 270 degrees. No dead space around the vehicle for unloading Chute With 2 removable secondary chutes to increase the discharge length. Tilt of mixing tank 16° Bucket Capacity 0.7 cubic meters Bucket Discharge Switch Hydraulic gates, electronically controlled Control lever Electrically controlled push-button 4-way pilot handle Traveling hydraulics pump Torque converter (MINGJ) Working hydraulics Pumps/Valves Mixing systems Speed reducer Stirring motor (Zhenjiang Dali) Drive axle Liufeng tanker truck special steering axle (20T) Water supply system Upper water: Hydraulically driven self-priming water pumps. Input voltage With two batteries 24V,100A. Hydraulic oil tank Capacity 120 liters 68 hydraulic oil for summer, 46 hydraulic oil for winter, with 35 hydraulic oil for cold areas. Equipped with liquid level meter. Tank volume 700L Diesel fuel tank volume 160L Quantity Weight 9000KG CAB Anti-fall cabs Adjustable steering wheel Adjustable seat Seat belts Fire extinguishers Reversing camera Roof-mounted warning lights standard equipment Radio standard equipment Escape hammers standard equipment Reversing Sound Alert standard equipment Travel control mode Standard: Mechanical Optional: Electric control Options
● Engine brand (make up the difference).
● Cooling and heating air conditioning (2000).
● Electronic weighing system (5000).
● High pressure car wash (2000).
● Electronic control traveling system (2000).
● Cement hopper (1000).
● Imported plunger motor (5000).
● Bucket Vibrator (1000).
● 360°Reverse Camera (500).
Free accessories
No. Name Quantities 1 Engine Oil Filter 1 set 2 Engine Air Filter 1 set 3 Engine Diesel Filter 1 set 4 15 Regulator 1 5 Flame Out Controller 1 6 Water Pump coupling 1 7 Water Pump coupling pads 1 8 Gaskets Generation 1 9 Fuse panel 1 box 10 Grease nipple 10 11 Toolboxes 1 box
