TL3600
Still deciding? Get samples first, Contact US !
View similar products
Tag list
- Description
-
Countries we are dealing with
MODEL NO TYPE Integral frame chassis movable, self loading, mixing, transporting Drum / cab / boom Synchronous rotation FUNCTION Concrete, sand, fertilizer compound, wet or dry feed materias mixing and discharging PRODUCTIVITY BATCH≤15MINS, 4BATCHS/14.4m³ Driver 4 x 4 Steering Front steering Motor YUNNEI 4 cylinders 2400 rpm, 92KW. intercooled supercharged ENGINE YUNNEI ENGINE: FOUR-CYLINDER 2400RPM,92KW SPEED HIGH SPEED: 40KM/H; LOW SPEE:7.5KM/H Gear number 4 forward shift ,4reverse shift TIRE Front twin tire (Steel wire tyre) DRUM Geometric volume 5.3 cubic meters, the best stirring 3.0-3.6 cubic meters Spiral blade in tank Double helix mixing, with the guide screw, so that the mixing material more uniform.Turn the feed left, turn the discharge right mixing tank 270°discharges 90 ° left/180 ° right There is no dead Angle for discharging around the vehicle TIPPING CHUTE Equipped with 2 chute for detachable to increase discharging length Tilt of mixing tank 16° SHOVEL 0.6立方 shovel capacity: 0.6m³ Bucket discharge switch Hydraulic gate, electric control OPERATION HANDLE ELECTRIC CONTROL BUTTON FOUR-WAY GUIDE HANDLE MOVING HYDRAULIC （DENGHONG）PUMP:DENGHONG Torque converter（MINGJ） Work hydraulic PUMP/valve: DENGHONG Mixing system SPEED REDUCER:（MINGJ） Mixing motor（ZHENJIANG DALI） Drive axle Extra Large Wheel Side Bridge WATER SUPPLY HYDRAULIC DRIVING SELF-PRIMIING PUMPS. VOLTAGE Battery 24V-100A 2 pieces HYDRAULIC OIL BOX TANKAGE115L, SUMMER:NO68 HYDRAULIC OIL, WINTER:NO46 HYDRAULIC OIL, VERY COLD ZONE: NO35 HYDRAULIC OIL Water tank capacity 720L Diesel tank capacity 90L Whole weight COMPLETE VEHICLE KERB MASS 8000kg CAB Prevent falling objects cab Adjustable steering wheel Adjustable seat Seat belts Fire extinguisher Astern image ALARM LAMP STANDARD CONFIGURATION RADIO STANDARD CONFIGURATION ESCAPE HAMMER STANDARD CONFIGURATION Astern sound prompt STANDARD CONFIGURATION Walking control mode STANDARD CONFIGURATION：mechanical Optional：Electric control Overall size drawing
Optional
● Engine brand.
● A/C.
● Electronic weighing system.
● High pressure car washing machine.
● Electric control walking system.
● Cement storage hopper.
● Imported piston motor.
● Vibrator for bucket.
● 360 ° reversing image.
Free spare parts
No. Name Quantity 1 Engine Oil Filter 1 set 2 Engine Air Filter 1 set 3 Engine Diesel Filter 1 set 4 15Pressure regulating valve 1 5 Flameout controller 1 6 Pump coupling 1 7 Pump coupling pad 1 8 Gasket Generation 1 9 Insurance piece 1 box 10 Grease nipple 10 11 Toolbox 1 set
Packaging for shipment
Customer Visits
Client Testimonials
TL3600
Still deciding? Get samples first, Contact US !
Products Category
Tag list
Qualification
FAQs
Where is your factory?
The factory of Weihai Titan Heavy Machinery Co. Ltd is in Qianyatou village,Mihe town,Qingzhou city,a long history dity with beautifulscenery and rich culture.
There are our office addresses also:
1:No .190-1 Wenhua WestRoad,Weihai City.
2:No .357 Songlin Road,Pudong NewArea,Shanghai.
3:Qianyatou Village,MiheTown,Qingzhou City.
What certificates do you have?
QUALITY MANAGEMENT SYSTEM CERTIFICATION：GB/T19001-2016/MS09001:2015
CE CERTIFICATION
NOISE TECHNICAL CONSTRUCTION FILE
MSDS FOR BATTERY
SABER CERTIFICATION
Can I get some samples?
Free sample is not available,and the minimum order quantity is one set.
Are you a factory or a trading company?
We are an integrated production and sales company,and both our production and sales teams have over 21 years of experience.
What is the MOQ of the product and what is the production lead time after ordering?
MOQ is 1,and the production lead time depends on the quantity of products ordered and is usualy around 15-30 days.
What are the payment options?
T/T payment is preferred,other payment methods are also accepted,payment terms:30% advance payment,70% balance payment.
Can't find the product you need?
Get in touch today and learn more of the Strength and Diversity of the Titan product range.
CONTACT US
Phone number:
Email:
Address:
Wehai:No 190-1,Culture of west road,Shandong provenice
Qingzhou:
Shanghai:
